EELBATTERY V4 DIY JK 200A BMS LifePO4 280Ah Metal Battery Case , EU stock

Specification

Battery Type: For 280Ah/304Ah/306Ah/314Ah Cell
Material:Steel
Communication: CANBUS and RS485(accept both)
BMS: 48V 16S JK-PB2A16S 15p/20p
Nominal Voltage:51.2V
Current :200A
Warranty:5 Years
Battery Pack Type: Stackable
OEM/ODM: Available
Weight:28kg
Size:415*700*263mm

Parts List(does not come with the battery cells)

1 * V4  JK Battery Case (Bottom case, Front Bracket, 2*Top Bracket, Front Panel,Top cover)
16 * Epoxy board(Between cell and the case)
2 * PCB Board(with sheet copper wires) for BMS and Cells Connection+2*matched EVA Tape
1 * 4.3-inch touch screen and matching switch
1 * 48V 16S JK BMS(JK-PB2A16S15P/JK-PB2A16S20P)+2*BMS wires
1 * Circuit Breaker
2 * Battery Terminals (P+ Terminal and P- Terminal)
4 * Customized Cables (BMS connection)
15 * Flexible busbars (Cell connection)
4 * Handle
4 * Upper and Lower Latch lock
10 * EVA Tape (Between cells)
Other Small Accessories

JK BMS software:

https://drive.google.com/drive/folders/1T7Amp5mqtl4twecgZRhJCK4hoWncbNDE

The heating elements will be shipped from China and are expected to take 10 working days to arrive.
