Model: EEL-48V-ENV1
Operating Voltage: 48-57.6V
Energy: 15kWh
Scalability: Up to 15 units (225kWh) can be connected in parallel
Depth of Discharge (DOD): ≥95%
Cycle Life: ≥8000 cycles
Communication: RS485/CAN
Protection Rating: IP21
ข้ามไปยังข้อมูลสินค้า
Nominal voltage: 51.2V
EEL 48V EN Vertical LiFePO4 Battery, For Home Solar Storage
Product Introduction
This upright low-voltage battery system is designed primarily for home solar power systems. It features built-in Class T fuses and an intelligent BMS system, providing multiple safeguards for intelligent battery management and timely protection of your home applications.
Product Advantages:
●Made with high-quality lithium iron phosphate batteries.
●Large capacity, compact size, suitable for home use.
●≥8000 deep-cycle charge and discharge cycles.
●High safety rating with built-in BMS protection.
●Expandable up to 16 units in parallel.
●Long-term warranty of up to 5 years.
●Certifications: CE-EMC, IEC 62619
$1,859.00
Reliable shipping
Flexible returns
Specification(Preassembled Standing Battery)
Nominal voltage: 51.2V
Nominal capacity: 280/314Ah
Energy storage: 15/16kWh
Series or parallel connection: 16S1P
Dimensions: 45*27*82.5cm (15/16kWh models)
Built-in battery management system: 16S 200A EN Bluetooth battery management system
Net weight: 110/130/140kg
Communication method: RS485/CAN bus
Charging current: 150A
Maximum charging current: 200A
Charging voltage: 56-57.6V
BMS cut-off voltage: 57.6V
Reconnection voltage: 54.6V
Built-in battery cells:
15kWh (CATL 280Ah)
16kWh (CALB 314Ah)
Maximum number of parallel units: 15
Parts List
1 *EEL 48V vertical lithium iron phosphate battery pack (15/16 kWh)
1 *50 mm² power cable set (1 red, 1 black, 2 meters long)
1 *RS485 to USB communication cable (for host computer communication)
1 *2-meter communication cable (battery to inverter)
DownLoad the software:
https://drive.google.com/drive/folders/1BdpkjrWTS8rM7Ph8gk29n09wh8JujVtX?usp=sharing
Bluetooth App(Android):
https://drive.google.com/file/d/1VkqUj50UKesQP7QZY3ZWnT9a0iyax6rt/view?usp=sharing
Free shipping from China warehouse:40~50 working days delivery
